DP-MB545CX
Product ID: DP-MB545CX
Name: A3 MULTI FUNCTION PRINTER
Description: Print, Scan, Copy, Fax, Wi-Fi, Duplex (45ppm)
Category: Printers
Brand: Panasonic
Brochure: DP-MB545CX DP-MB536CX
|
|
|
New Page 1
The All New DP-MB545CX
Specification
| |
DP-MB545 |
DP-MB536 |
|
General |
Recording Paper Size (Simplex) |
Input Tray : A4, A5, A6, LTR, B5(ISO/JIS), 16K |
|
Multi-purpose tray : A3, A4, A5, A6, Ledger, LTR, LGL, Folio/Foolscap
(216 x 330 mm), Oficio (216 x 340 mm), B4(ISO/JIS), B5(ISO/JIS), |
|
B6(ISO/JIS), 16K, 8K,Envelope #10/DL/YOUKEI #4/CHOUKEI #3/CHOUKEI #4,
Japanese Postcard, Custom (W: 85-297 mm, L: 200-600mm) |
|
Printing Process |
Laser |
|
Recording Paper Capacity |
Max: 1,750 sheets [Standard input tray: 550 sheets / Multi-purpose tray:
100 sheets / Optional lower input tray: 550 sheets x 2) |
Max: 1,200 sheets [Standard input tray: 550 sheets / Multi-purpose tray:
100 sheets / Optional lower input tray: 550 sheets x 1) |
|
Recording Paper Weight |
- Standard input tray: 60 g/m² - 105 g/m² (Simplex and Duplex) |
|
- Multi-purpose tray: 60 g/m² - 220 g/m² (Simplex), 60 g/m² - 105 g/m²
(Duplex) |
|
Automatic Document Feeder Capacity |
75 sheets |
|
Document Size |
Automatic Document
Feeder |
Single-sided: A4, A5, A5, LTR, LGL, B5(JIS/ISO), B6(JIS/ISO), 16K,
Folio/Foolscap (216 x 330 mm), Oficio (216 x 340 mm), Long paper (W:
210-216 mm, L:356-600 mm) |
|
Double-sided: A4, A5, A6, LTR, LGL, B5(JIS/ISO), B6(JIS/ISO), 16K,
Folio/Foolscap (216 x 330 mm), Oficio (216 x 340 mm) |
|
Flatbed |
Up to LGL |
|
LCD Display |
4.3-inch Colour Touch Screen |
16 digits / 2 lines (Backlit LCD) |
|
Memory Size |
1.024 MB |
512 MB |
|
Department Code |
100 |
|
Quick Job Key |
10 jobs (Shared between Copy and Scan) |
Copy: 3 jobs / Scan: 3 jobs |
|
Monthly Duty |
Average: 10,000 pages / Maximum: 150,000 pages |
|
Power Consumption |
Max.: Approx. 1,550 W, Copy: Approx. 800 W, Ready: Approx. 90 W, Sleep:
Less than 2.2 W (USB connection)
Less than 2.6 W (Wired LAN) / 3.0 W (Wireless LAN) |
|
Computer Interface |
IEEE802.11b/g/n, 1000Base-T, 100Base-TX/10Base-T, USB2.0 |
|
Media Port |
USB |
|
PC I/F |
USB |
2.0 Hi-Speed |
|
Network Interface |
10Base-T / 100Base- TX / 1000Base-T |
10Base-T / 100Base- TX |
|
Wi-Fi (IEEE802.11b/g/n) |
|
Printer |
Print Speed |
Up to 45 ppm (A4), Up to 24 ppm (A3) |
Up to 36 ppm (A4), Up to 20 ppm (A3) |
|
Duplex Productivity |
100 % (45 ppm, A4) |
100 % (36 ppm, A4) |
|
Print Resolution |
Up to 1,200 x 1,200 dpi (True) |
|
First Print Time |
Approx. 5 s |
|
Emolation |
Adobe® PostScript® 3™, PCL 6, GDI |
PCL 6, GDI |
|
Supported OS for Printer |
Windows® XP, Windows Vista®, Windows® 7, Windows 8, Windows 8.1, Windows
10, Windows Server® 2008, Windows Server® 2012, Mac OS X 10.5-10.11,
Linux® |
|
Copier |
Copy Speed |
Up to 45 cpm (A4) |
Up to 36 cpm (A4) |
|
Copy Resolution |
Up to 1,200 x 1,200 dpi |
|
Multi-Copy |
99 pages |
|
First Copy Time |
Approx. 5 s (Flatbed copy) |
|
Scanner |
Colour / Mono Scan |
Yes / Yes |
|
Scan Resolution |
Optical: Up to 1,200 x 1,200 dpi, Interpolated: Up to 19,200 x 19,200
dpi |
|
Duplex Scan |
Yes |
|
Scan Speed (B/W, 300 dpi) |
Simplex: 45 ppm / Duplex: 16 ppm |
|
Supported OS for Scanner |
Windows® XP, Windows Vista®, Windows® 7, Windows 8, Windows 8.1, Windows
10, Mac OS X 10.5-10.11, Linux® |
|
Facsimile |
Fax Modem Speed |
33.6 kbps -2.4 kbps with automatic fallback |
|
Internet Fax |
Yes |
|
Fax Memory Capacity |
Reception: Approx. 400 pages, Transmission: Approx. 200 pages |
|
Address Book |
300 and LDAP |
300 + 6 and LDAP |
|
One-Touch Dial |
- |
6 |
|
Fax / Tel Switch |
Yes |
|
Handset |
Yes |
|
Dimension (W x D x H) |
|
Approx. 530 x 475 x 615 mm (With trays closed) / Approx. 606 x 726 x 680
mm (With both multi-purpose tray and document trays open) |
|
Weight |
|
Approx. 31.2 kg |
|
Consumable |
Toner Cartridge |
DQ-TCD025E (25,000 pages, ISO/IEC 19752 standard) |
|
DQ-TCD025ED (2 x 25,000 pages, ISO/IEC 19752 standard) |
|
Drum Cartridge |
DQ-DCD100E (100,000 pages) |
|
|
